- Country of Manufacture:
- United States
- Agency Approvals:
- Type USE-2 per UL 854, RHH/RHW-2 per UL 44, Type PV per UL 4703
- Feet/Pound:
- 11.43
- Resistant to:
- Sunlight, ozone, UV, flame, and moisture
- Display Weight:
- 5.28
- Nominal Outside Diameter:
- 0.29
- Insulation Material:
- Cross-linked Polyethylene (XLP)
- Max Temperature Rating:
- 90°CC
- Min Temperature Rating:
- 90°CC
- Conductor Stranding:
- 19 / 0.0185
- Insulation Thickness:
- 0.045
- Conductor Material:
- Bare copper
- Maximum Voltage:
- 600
- Conductor Size:
- 8 AWG
- Length Ft:
- 60
- Amps per Conductor:
- 55
- Conductor Type:
- Stranded
- Jacket Color:
- Red
1 Review
-
Great solar wire
I have a long line, 250', with only a very small volt drop from 73 to 67. Only 6 volts. I added this 60 footer to it but not tested it for volt drop. The system is happy with it though, I knew it would.
