TEMCo Euro Standard Transformer TT1091 - 3 kVA

TEMCo Direct: $975.00
No reviews yet Write a Review
SKU:
TT1091
Availability:
Build to order in aprox 12 weeks
Weight:
55.00 LBS
Width:
9.00 (in)
Height:
6.75 (in)
Depth:
6.00 (in)
Shipping:
$368.00 (Fixed Shipping Cost)
Output Amps at:
380V4.56
400V4.33
415V4.17

TEMCo Euro Standard transformers are used to convert standard 3 phase US voltages to standard European voltages. This is useful when importing European Machinery into the U.S. Additionally, these transformers are rated for either 50Hz or 60Hz, allowing them be connected in reverse to convert European voltages to U.S. voltages when importing U.S. machinery into Europe. Either way, these transformers are built to last, guaranteed. That's why we back these with a decade long warranty.

Don't have floor space to mount your TEMCo Euro-Standard transformer? No problem! Heavy duty wall mounting brackets are supplied on all Euro-Standard transformers up to 45 kVA. For larger units, take advantage of the weather shields included with every unit and mount your Euro-Standard transformer outside. Save your valuable floor space for your machinery instead of cluttering it with electrical equipment.

Connections are made simple with TEMCo Euro-Standard transformers. Multiple taps are provided on the output for 380, 400, or 415 V Wye configured outputs. All your input and output connections can be made via the provided fast connection lugs. Rigid GPO-3 fiberglass primary buss strut ensures that connections remain secure through the life of the installation.


Bil Rating Kv:
4
Temperature Rise:
100
Insulation System:
155
Manufacturer:
TEMCo
Enclosure Rating:
NA
Input Voltage:
208
Output Voltage:
380/400/415
Enclosure Material:
NA
UL Listed:
NO
CSA Approved:
NO
Transformer Type:
Isolation
Phase:
Three
Kva:
3
Winding Material:
Copper
Primary Configuration:
Delta
Secondary Configuration:
Wye
Reverse Connectable:
NO
Electrostatically Shielded:
NO
Construction Style:
Open (Core & Coil)
Cooling:
NA
Connection Type:
Lugs / Bolt-down terminals
Frequency Hz:
60
K Rating:
1
Mounting Type:
Base/panel
Sound Level db:
Less than 40 dB
10 Years
