We've taken the time to coat the male poppet end with Titanium Nitride (Ti-Ni). Persistent coupling and decoupling along with inevitable particulates getting between the couplers leads to scratches and abrasions. These inconsistencies will eventually lead to a poor seal, resulting in leaks and loss of pressure. Ti-Ni coatings are usually used on drill bits and high speed steel to solve the problem of abrasion, so we decided to coat the business end of our male couplers with it. Also, we think the gold looks pretty slick.
Our couplers are machined out of carbon steel and plated with Zinc Nickel (Zn-Ni), which offers corrosion resistance, as well as an extra layer against normal wear and tear. Each coupler is pressure tested with hydraulic oil right off the factory line.
So, whether you're buying a replacement or making an upgrade to your skidsteer or agricultural equipment, TEMCo's hydraulic flat face couplers are designed to withstand your roughest working environment.
Rotate the knurled collar on the female coupler so that the ball and indent in the collar are misaligned. Doing so will prevent the collar from being pulled back, which disengages and releases the female coupler from the male coupler. This feature ensures a safe working environment. To disengage the coupler, simply rotate the collar into alignment and pull the collar back away from the opposing male coupler.
- Carbon Steel construction, Zinc Nickel coating, and Titanium Nitride Male Poppets.
- Titanium Nitride, often used for high speed steel drill bits, provides a longer wear life and proper seal after persistent usage.
- A removable cap is attached to the coupler body, further preventing contaminant ingress.
- Coupler Compatibility:
- Tractors and Ag Equipment Fits Pioneer Parker Format
- Zinc Nickel
- Body Material:
- Carbon Steel
- Poppett Coating:
- Titanium Nitride
- Rated Flow:
- 50.19 Gallons per Minute (GPM)
- Polyurathane Seal Temp range:
- -13°F to 193°F
- NBR Seal Temp Range:
- -4°F to 176°F
- PTFE Seal Temp Range:
- -148°F to 262°F
- Rated Pressure:
- 3625.94 PSI
- Cap Inculded:
- Hydraulic Coupler ISO number:
- Hydraulic Coupler Thread:
- 3/4 inch NPT
- Hydraulic Coupler Valve:
- Hyrdaulic Coupler Connection:
